Huion Kamvas 22 (Gen 3) vs XP-Pen Artist Pro 22 (Gen 2)
What Kamvas 22 (Gen 3) does better (3) and where Artist Pro 22 (Gen 2) wins (1) — every spec side by side.
vs
5.7Screen5.0
9.1Pen & controls7.0
5.9Connectivity5.9
4.9Design & ergonomics3.8
Dimensions
Size comparison
Kamvas 22 (Gen 3)Artist Pro 22 (Gen 2)
| Kamvas 22 (Gen 3) | Artist Pro 22 (Gen 2) | Difference | |
|---|---|---|---|
| Height | 324.7 mm | 362 mm | −37.3 mm |
| Width | 527.7 mm | 547 mm | −19.3 mm |
| Depth | 16 mm | 33.4 mm | −17.4 mm |
| Weight | 3.6 kg | 5.6 kg | −1.9 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Kamvas 22 (Gen 3) better than Artist Pro 22 (Gen 2)?
- Report rate260 RPS vs 220 RPS+18%
- Weight3.6 kg vs 5.55 kg+54%
- Pen accuracy (centre)±0.3 mm vs ±0.4 mm+33%
Why is Artist Pro 22 (Gen 2) better than Kamvas 22 (Gen 3)?
- Pixel density121 ppi vs 137 ppi+13%
Specifications
Side by side
| Display | ||
| Screen size | 21.5″ | 21.5″ |
| Resolution | 2560 × 1440 | 2560 × 1440 |
| Resolution class | QHD / 2.5K | QHD / 2.5K |
| Pixel density | 121 ppi | 137 ppi |
| Aspect ratio | 16:9 | 16:9 |
| Panel type | IPS | — |
| Refresh rate | 90 Hz | — |
| Brightness (typical) | 250 nits | 250 nits |
| Contrast ratio (static) | 1,000:1 | 1,000:1 |
| Response time | 14 ms | — |
| Anti-glare / matte screen | Yes | Yes |
| Fully laminated screen | Yes | Yes |
| Colour | ||
| sRGB coverage | — | 99% |
| Adobe RGB coverage | — | 99% |
| DCI-P3 coverage | — | 94% |
| Colour depth | 8 bit | 8 bit |
| Pen & controls | ||
| Pressure levels | 16,384 | 16,384 |
| Tilt recognition | ±60° | ±60° |
| Active area | 475.4 × 267.4 mm | 475.4 × 267.4 mm |
| Active area width | 475 mm | 475 mm |
| Active area height | 267 mm | 267 mm |
| Active area (surface) | 1,271 cm² | 1,271 cm² |
| Pen resolution | 5,080 lpi | 5,080 lpi |
| Report rate | 260 RPS | 220 RPS |
| Pen accuracy (centre) | ±0.3 mm | ±0.4 mm |
| Battery-free pen | Yes | Yes |
| Pen with eraser | — | Yes |
| Pen | PW600L (PenTech 4.0) | X3 Pro Smart Chip Stylus |
| Multi-touch | No | No |
| Connectivity | ||
| USB-C video input (one cable) | Yes | Yes |
| HDMI inputs | 1 | 1 |
| Wireless connection | No | No |
| Compatibility | Windows, macOS, Android | Windows, macOS, Linux, Android, ChromeOS |
| Design & ergonomics | ||
| Stand | Adjustable Stand 20°~80° | — |
| Weight | 3.6 kg | 5.55 kg |
| Width | 528 mm | 547 mm |
| Height | 325 mm | 362 mm |
| Depth | 16 mm | 33 mm |
| Product line | Huion Kamvas | XP-Pen Artist |
