Wacom Cintiq Pro 16 vs Wacom Cintiq Pro 24
What Cintiq Pro 16 does better (4) and where Cintiq Pro 24 wins (4) — every spec side by side.
vs
8.6Screen8.1
6.7Pen & controls8.5
3.8Connectivity3.8
6.3Design & ergonomics3.1
Dimensions
Size comparison
Cintiq Pro 16Cintiq Pro 24
| Cintiq Pro 16 | Cintiq Pro 24 | Difference | |
|---|---|---|---|
| Height | 265 mm | 394 mm | −129 mm |
| Width | 410 mm | 677 mm | −267 mm |
| Weight | 1.5 kg | 7 kg | −5.5 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Cintiq Pro 16 better than Cintiq Pro 24?
- Pixel density284 ppi vs 187 ppi+52%
- Weight1.5 kg vs 7 kg4.7×
- Brightness (typical)300 nits vs 235 nits+28%
- Multi-touchYes · Cintiq Pro 24: No
Why is Cintiq Pro 24 better than Cintiq Pro 16?
- Express keys8 vs 172.1×
- Active area (surface)669 cm² vs 1,535 cm²2.3×
- Response time30 ms vs 14 ms2.1×
- Screen size15.6″ vs 23.6″+51%
Specifications
Side by side
| Display | ||
| Screen size | 15.6″ | 23.6″ |
| Resolution | 3840 × 2160 | 3840 × 2160 |
| Resolution class | 4K UHD | 4K UHD |
| Pixel density | 284 ppi | 187 ppi |
| Aspect ratio | 16:9 | 16:9 |
| Panel type | IPS | — |
| Brightness (typical) | 300 nits | 235 nits |
| Contrast ratio (static) | 1,000:1 | 1,000:1 |
| Response time | 30 ms | 14 ms |
| Anti-glare / matte screen | Yes | — |
| Pen & controls | ||
| Pressure levels | 8,192 | 8,192 |
| Tilt recognition | ±60° | ±60° |
| Active area | 345 × 194 mm | 522 × 294 mm |
| Active area width | 345 mm | 522 mm |
| Active area height | 194 mm | 294 mm |
| Active area (surface) | 669 cm² | 1,535 cm² |
| Pen resolution | 5,080 lpi | 5,080 lpi |
| Battery-free pen | Yes | Yes |
| Express keys | 8 | 17 |
| Multi-touch | Yes | No |
| Connectivity | ||
| USB-C video input (one cable) | No | No |
| HDMI inputs | 1 | 1 |
| DisplayPort inputs | 1 | 1 |
| Wireless connection | No | No |
| Compatibility | Windows, macOS | Windows, macOS |
| Design & ergonomics | ||
| Weight | 1.5 kg | 7 kg |
| Width | 410 mm | 677 mm |
| Height | 265 mm | 394 mm |
| Depth | 18 mm | — |
| Product line | Wacom Cintiq Pro | Wacom Cintiq Pro |
