GAOMON PD1220 vs Huion Kamvas 13
What PD1220 does better (1) and where Kamvas 13 wins (2) — every spec side by side.
Dimensions
Size comparison
PD1220Kamvas 13
| PD1220 | Kamvas 13 | Difference | |
|---|---|---|---|
| Height | 144 mm | 217.4 mm | −73.4 mm |
| Width | 256 mm | 366.5 mm | −110.5 mm |
| Depth | 4.5 mm | 11.8 mm | −7.3 mm |
| Weight | 0.7 kg | 1 kg | −0.2 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is PD1220 better than Kamvas 13?
- Weight0.74 kg vs 0.98 kg+32%
Why is Kamvas 13 better than PD1220?
- USB-C video input (one cable)No · PD1220: Yes
- Report rate220 RPS vs 266 RPS+21%
Specifications
Side by side
| Display | ||
| Screen size | — | 13.3″ |
| Resolution | 1920 × 1080 | 1920 × 1080 |
| Resolution class | Full HD | Full HD |
| Pixel density | — | 166 ppi |
| Aspect ratio | 16:9 | 16:9 |
| Panel type | IPS | IPS |
| Brightness (typical) | 220 nits | 220 nits |
| Contrast ratio (static) | — | 1,000:1 |
| Response time | — | 25 ms |
| Anti-glare / matte screen | Yes | Yes |
| Fully laminated screen | — | Yes |
| Colour | ||
| Colour depth | — | 8 bit |
| Pen & controls | ||
| Pressure levels | 8,192 | 8,192 |
| Tilt recognition | ±60° | ±60° |
| Active area | — | 293.8 × 165.2 mm |
| Active area width | — | 294 mm |
| Active area height | — | 165 mm |
| Active area (surface) | — | 485 cm² |
| Pen resolution | 5,080 lpi | 5,080 lpi |
| Report rate | 220 RPS | 266 RPS |
| Pen accuracy (centre) | — | ±0.5 mm |
| Battery-free pen | — | Yes |
| Pen | — | PW517 |
| Express keys | — | 8 |
| Multi-touch | No | No |
| Connectivity | ||
| USB-C video input (one cable) | No | Yes |
| HDMI inputs | 1 | — |
| Wireless connection | No | No |
| Compatibility | Windows, macOS, Android | Windows, macOS, Linux, Android |
| Design & ergonomics | ||
| Stand | — | ST300(Optional) |
| Weight | 0.74 kg | 0.98 kg |
| Width | 256 mm | 366 mm |
| Height | 144 mm | 217 mm |
| Depth | 4 mm | 12 mm |
| Product line | — | Huion Kamvas |
