- PD2200 vs Kamvas 22 (Gen 3)
GAOMON PD2200 vs Huion Kamvas 22 (Gen 3)
What PD2200 does better (1) and where Kamvas 22 (Gen 3) wins (5) — every spec side by side.
vs
2.6Screen5.8
7.6Pen & controls9.1
2.8Connectivity6.2
4.8Design & ergonomics5.0
Dimensions
Size comparison
PD2200Kamvas 22 (Gen 3)
| PD2200 | Kamvas 22 (Gen 3) | Difference | |
|---|---|---|---|
| Height | 316 mm | 324.7 mm | −8.7 mm |
| Width | 522 mm | 527.7 mm | −5.7 mm |
| Depth | 9.5 mm | 16 mm | −6.5 mm |
| Weight | 3.8 kg | 3.6 kg | +0.2 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is PD2200 better than Kamvas 22 (Gen 3)?
- Report rate266 RPS vs 260 RPS+2%
Why is Kamvas 22 (Gen 3) better than PD2200?
- Pressure levels8,192 vs 16,3842×
- USB-C video input (one cable)No · PD2200: Yes
- Pixel density102 ppi vs 121 ppi+19%
- Brightness (typical)220 nits vs 250 nits+14%
- Weight3.84 kg vs 3.6 kg+7%
Specifications
Side by side
| Display | ||
| Screen size | 21.5″ | 21.5″ |
| Resolution | 1920 × 1080 | 2560 × 1440 |
| Resolution class | Full HD | QHD / 2.5K |
| Pixel density | 102 ppi | 121 ppi |
| Aspect ratio | 16:9 | 16:9 |
| Panel type | IPS | IPS |
| Refresh rate | — | 90 Hz |
| Brightness (typical) | 220 nits | 250 nits |
| Contrast ratio (static) | 1,000:1 | 1,000:1 |
| Response time | — | 14 ms |
| Anti-glare / matte screen | Yes | Yes |
| Fully laminated screen | — | Yes |
| Colour | ||
| Colour depth | — | 8 bit |
| Pen & controls | ||
| Pressure levels | 8,192 | 16,384 |
| Tilt recognition | ±60° | ±60° |
| Active area | 477 × 268 mm | 475.4 × 267.4 mm |
| Active area width | 477 mm | 475 mm |
| Active area height | 268 mm | 267 mm |
| Active area (surface) | 1,278 cm² | 1,271 cm² |
| Pen resolution | 5,080 lpi | 5,080 lpi |
| Report rate | 266 RPS | 260 RPS |
| Pen accuracy (centre) | — | ±0.3 mm |
| Battery-free pen | Yes | Yes |
| Pen | — | PW600L (PenTech 4.0) |
| Express keys | 8 | — |
| Multi-touch | No | No |
| Connectivity | ||
| USB-C video input (one cable) | No | Yes |
| HDMI inputs | 1 | 1 |
| Wireless connection | No | No |
| Compatibility | Windows, macOS | Windows, macOS, Android |
| Design & ergonomics | ||
| Stand | — | Adjustable Stand 20°~80° |
| Weight | 3.84 kg | 3.6 kg |
| Width | 522 mm | 528 mm |
| Height | 316 mm | 325 mm |
| Depth | 10 mm | 16 mm |
| Product line | — | Huion Kamvas |
