- Kamvas 24 Plus vs Artist Pro 24 165Hz (Gen 2)
Huion Kamvas 24 Plus vs XP-Pen Artist Pro 24 165Hz (Gen 2)
What Kamvas 24 Plus does better (2) and where Artist Pro 24 165Hz (Gen 2) wins (3) — every spec side by side.
vs
4.8Screen6.7
6.2Pen & controls7.5
7.9Connectivity5.2
3.6Design & ergonomics2.2
Dimensions
Size comparison
Kamvas 24 PlusArtist Pro 24 165Hz (Gen 2)
| Kamvas 24 Plus | Artist Pro 24 165Hz (Gen 2) | Difference | |
|---|---|---|---|
| Height | 358 mm | 408 mm | −50 mm |
| Width | 604.2 mm | 638 mm | −33.8 mm |
| Depth | 21 mm | 44 mm | −23 mm |
| Weight | 5.6 kg | 7.3 kg | −1.7 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Kamvas 24 Plus better than Artist Pro 24 165Hz (Gen 2)?
- Pen accuracy (centre)±0.3 mm vs ±0.4 mm+33%
- Weight5.6 kg vs 7.3 kg+30%
Why is Artist Pro 24 165Hz (Gen 2) better than Kamvas 24 Plus?
- Pressure levels8,192 vs 16,3842×
- Brightness (typical)220 nits vs 250 nits+14%
- Response time14 ms vs 11 ms+27%
Specifications
Side by side
| Display | ||
| Screen size | 23.8″ | 23.8″ |
| Resolution | 2560 × 1440 | 2560 × 1440 |
| Resolution class | QHD / 2.5K | QHD / 2.5K |
| Pixel density | 123 ppi | 123 ppi |
| Aspect ratio | 16:9 | — |
| Panel type | IPS | — |
| Refresh rate | — | 165 Hz |
| Brightness (typical) | 220 nits | 250 nits |
| Contrast ratio (static) | 1,200:1 | — |
| Response time | 14 ms | 11 ms |
| Anti-glare / matte screen | Yes | Yes |
| Fully laminated screen | Yes | Yes |
| Colour | ||
| sRGB coverage | — | 99% |
| Adobe RGB coverage | — | 99% |
| DCI-P3 coverage | — | 94% |
| Colour depth | 8 bit | 8 bit |
| Factory calibrated (report) | — | Yes |
| Pen & controls | ||
| Pressure levels | 8,192 | 16,384 |
| Tilt recognition | ±60° | ±60° |
| Active area | 526.9 × 296.4 mm | 526 × 296 mm |
| Active area width | 527 mm | 526 mm |
| Active area height | 296 mm | 296 mm |
| Active area (surface) | 1,562 cm² | 1,557 cm² |
| Pen resolution | 5,080 lpi | 5,080 lpi |
| Report rate | 220 RPS | 220 RPS |
| Pen accuracy (centre) | ±0.3 mm | ±0.4 mm |
| Battery-free pen | Yes | Yes |
| Pen with eraser | — | Yes |
| Pen | PW517 | X3 Pro Smart Chip Stylus + X3 Pro Slim Stylus |
| Multi-touch | No | No |
| Connectivity | ||
| USB-C video input (one cable) | Yes | Yes |
| HDMI inputs | — | 1 |
| DisplayPort inputs | — | 1 |
| Wireless connection | No | No |
| Compatibility | Windows, macOS, Linux, Android | Windows, macOS, Linux, Android, ChromeOS |
| Design & ergonomics | ||
| Stand | Adjustable Stand 20°~80° | — |
| Weight | 5.6 kg | 7.3 kg |
| Width | 604 mm | 638 mm |
| Height | 358 mm | 408 mm |
| Depth | 21 mm | 44 mm |
| Product line | Huion Kamvas | XP-Pen Artist |
