- Cintiq 24 vs Cintiq Pro 24 Touch
Wacom Cintiq 24 vs Wacom Cintiq Pro 24 Touch
What Cintiq 24 does better (4) and where Cintiq Pro 24 Touch wins (2) — every spec side by side.
vs
6.5Screen8.0
6.9Pen & controls9.2
5.9Connectivity3.5
4.3Design & ergonomics2.5
Dimensions
Size comparison
Cintiq 24Cintiq Pro 24 Touch
| Cintiq 24 | Cintiq Pro 24 Touch | Difference | |
|---|---|---|---|
| Height | 340 mm | 394 mm | −54 mm |
| Width | 568 mm | 677 mm | −109 mm |
| Weight | 4.8 kg | 7.2 kg | −2.4 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Cintiq 24 better than Cintiq Pro 24 Touch?
- USB-C video input (one cable)Yes · Cintiq Pro 24 Touch: No
- Brightness (typical)350 nits vs 235 nits+49%
- Weight4.8 kg vs 7.2 kg+50%
- Response time12 ms vs 14 ms+17%
Why is Cintiq Pro 24 Touch better than Cintiq 24?
- Pixel density123 ppi vs 187 ppi+52%
- Multi-touchNo · Cintiq 24: Yes
Specifications
Side by side
| Display | ||
| Screen size | 23.8″ | 23.6″ |
| Resolution | 2560 × 1440 | 3840 × 2160 |
| Resolution class | QHD / 2.5K | 4K UHD |
| Pixel density | 123 ppi | 187 ppi |
| Aspect ratio | 16:9 | 16:9 |
| Panel type | IPS | — |
| Brightness (typical) | 350 nits | 235 nits |
| Contrast ratio (static) | 1,000:1 | 1,000:1 |
| Response time | 12 ms | 14 ms |
| Anti-glare / matte screen | Yes | — |
| Pen & controls | ||
| Pressure levels | 8,192 | 8,192 |
| Tilt recognition | ±60° | ±60° |
| Active area | 527 × 296 mm | 522 × 294 mm |
| Active area width | 527 mm | 522 mm |
| Active area height | 296 mm | 294 mm |
| Active area (surface) | 1,560 cm² | 1,535 cm² |
| Pen resolution | 5,080 lpi | 5,080 lpi |
| Report rate | 240 RPS | — |
| Battery-free pen | Yes | Yes |
| Express keys | — | 17 |
| Multi-touch | No | Yes |
| Connectivity | ||
| USB-C video input (one cable) | Yes | No |
| HDMI inputs | 1 | 1 |
| DisplayPort inputs | — | 1 |
| Wireless connection | No | No |
| Compatibility | Windows, macOS, Android | Windows, macOS |
| Design & ergonomics | ||
| Weight | 4.8 kg | 7.2 kg |
| Width | 568 mm | 677 mm |
| Height | 340 mm | 394 mm |
| Depth | 21 mm | — |
| Product line | Wacom Cintiq | Wacom Cintiq Pro |
