- Kamvas 13 vs Kamvas 24
Huion Kamvas 13 vs Huion Kamvas 24
What Kamvas 13 does better (4) and where Kamvas 24 wins (4) — every spec side by side.
Dimensions
Size comparison
Kamvas 13Kamvas 24
| Kamvas 13 | Kamvas 24 | Difference | |
|---|---|---|---|
| Height | 217.4 mm | 358 mm | −140.6 mm |
| Width | 366.5 mm | 604.2 mm | −237.7 mm |
| Depth | 11.8 mm | 21 mm | −9.2 mm |
| Weight | 1 kg | 5.6 kg | −4.6 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Kamvas 13 better than Kamvas 24?
- Pixel density166 ppi vs 123 ppi+35%
- Weight0.98 kg vs 5.6 kg5.7×
- Report rate266 RPS vs 220 RPS+21%
- Fully laminated screenYes · Kamvas 24: No
Why is Kamvas 24 better than Kamvas 13?
- Active area (surface)485 cm² vs 1,562 cm²3.2×
- Screen size13.3″ vs 23.8″+79%
- Response time25 ms vs 14 ms+79%
- Pen accuracy (centre)±0.5 mm vs ±0.3 mm+67%
Specifications
Side by side
| Display | ||
| Screen size | 13.3″ | 23.8″ |
| Resolution | 1920 × 1080 | 2560 × 1440 |
| Resolution class | Full HD | QHD / 2.5K |
| Pixel density | 166 ppi | 123 ppi |
| Aspect ratio | 16:9 | 16:9 |
| Panel type | IPS | IPS |
| Brightness (typical) | 220 nits | 220 nits |
| Contrast ratio (static) | 1,000:1 | 1,000:1 |
| Response time | 25 ms | 14 ms |
| Anti-glare / matte screen | Yes | Yes |
| Fully laminated screen | Yes | No |
| Colour | ||
| Colour depth | 8 bit | 8 bit |
| Pen & controls | ||
| Pressure levels | 8,192 | 8,192 |
| Tilt recognition | ±60° | ±60° |
| Active area | 293.8 × 165.2 mm | 526.9 × 296.4 mm |
| Active area width | 294 mm | 527 mm |
| Active area height | 165 mm | 296 mm |
| Active area (surface) | 485 cm² | 1,562 cm² |
| Pen resolution | 5,080 lpi | 5,080 lpi |
| Report rate | 266 RPS | 220 RPS |
| Pen accuracy (centre) | ±0.5 mm | ±0.3 mm |
| Battery-free pen | Yes | Yes |
| Pen | PW517 | PW517 |
| Express keys | 8 | — |
| Multi-touch | No | No |
| Connectivity | ||
| USB-C video input (one cable) | Yes | Yes |
| Wireless connection | No | No |
| Compatibility | Windows, macOS, Linux, Android | Windows, macOS, Linux, Android |
| Design & ergonomics | ||
| Stand | ST300(Optional) | Adjustable Stand 20°~80° |
| Weight | 0.98 kg | 5.6 kg |
| Width | 366 mm | 604 mm |
| Height | 217 mm | 358 mm |
| Depth | 12 mm | 21 mm |
| Product line | Huion Kamvas | Huion Kamvas |
