- Kamvas Pro 20 vs Cintiq 16
Huion Kamvas Pro 20 vs Wacom Cintiq 16
What Kamvas Pro 20 does better (2) and where Cintiq 16 wins (6) — every spec side by side.
vs
2.6Screen8.8
4.4Pen & controls5.7
3.5Connectivity2.6
4.9Design & ergonomics5.6
Dimensions
Size comparison
Kamvas Pro 20Cintiq 16
| Kamvas Pro 20 | Cintiq 16 | Difference | |
|---|---|---|---|
| Height | 315.3 mm | 285 mm | +30.3 mm |
| Width | 552.2 mm | 422 mm | +130.2 mm |
| Depth | 21 mm | 24.5 mm | −3.5 mm |
| Weight | 3.6 kg | 1.9 kg | +1.7 kg |
Drawn to the same scale from the official dimensions (front and side).
Why is Kamvas Pro 20 better than Cintiq 16?
- Active area (surface)1,038 cm² vs 666 cm²+56%
- Screen size19.5″ vs 15.5″+26%
Why is Cintiq 16 better than Kamvas Pro 20?
- Pixel density113 ppi vs 189 ppi+67%
- Brightness (typical)220 nits vs 290 nits+32%
- Response time25 ms vs 12 ms2.1×
- Report rate200 RPS vs 240 RPS+20%
- Weight3.6 kg vs 1.9 kg+89%
- Contrast ratio (static)1,000:1 vs 1,400:1+40%
Specifications
Side by side
| Display | ||
| Screen size | 19.5″ | 15.5″ |
| Resolution | 1920 × 1080 | 2560 × 1600 |
| Resolution class | Full HD | QHD / 2.5K |
| Pixel density | 113 ppi | 189 ppi |
| Aspect ratio | 16:9 | 16:10 |
| Panel type | IPS | IPS |
| Brightness (typical) | 220 nits | 290 nits |
| Contrast ratio (static) | 1,000:1 | 1,400:1 |
| Response time | 25 ms | 12 ms |
| Anti-glare / matte screen | Yes | Yes |
| Fully laminated screen | Yes | — |
| Colour | ||
| Colour depth | 8 bit | — |
| Pen & controls | ||
| Pressure levels | 8,192 | 8,192 |
| Tilt recognition | ±60° | ±60° |
| Active area | 434.9 × 238.7 mm | 344.2 × 193.6 mm |
| Active area width | 435 mm | 344 mm |
| Active area height | 239 mm | 194 mm |
| Active area (surface) | 1,038 cm² | 666 cm² |
| Pen resolution | 5,080 lpi | 5,080 lpi |
| Report rate | 200 RPS | 240 RPS |
| Pen accuracy (centre) | ±0.5 mm | — |
| Battery-free pen | Yes | Yes |
| Pen | PW507 | — |
| Express keys | 16 | — |
| Multi-touch | No | No |
| Connectivity | ||
| USB-C video input (one cable) | No | No |
| HDMI inputs | 1 | 1 |
| DisplayPort inputs | 1 | — |
| Wireless connection | No | No |
| Compatibility | Windows, macOS, Linux | Windows |
| Design & ergonomics | ||
| Stand | adjustable stand 20°~80° | — |
| Weight | 3.6 kg | 1.9 kg |
| Width | 552 mm | 422 mm |
| Height | 315 mm | 285 mm |
| Depth | 21 mm | 24 mm |
| Product line | Huion Kamvas | Wacom Cintiq |
